| Maximum Noise of the Machine without waste material as per IS12065:1987 latest amendment (dB) |
68 |
| Material of the Rotary Cutters/Discs conforming to Steel grade per IS 7494:1981 latest amendment |
40Cr4Mo3 |
| Number of Rotary Cutters/Discs |
10 |
| Short circuit protection system available |
Yes |
| Type of Drive motor |
Induction Motor |
| Machine suitable for Waste Category as per Bio-Medical Waste Management Rules, 2016 |
Red |
| Number of Rotating Shaft(s) |
1 |
| Power Cutoff upon opening of Shreding chamber door/acess |
Yes |
| Enclosure material |
Mild Steel |
| Hardness of shaft (HB) |
152 |
| IP rating of the machine |
40 |
| Power output of the motor |
3 horsepower |
| Number of Fixed Cutter |
1 |
| Material of the Fixed Cutters conforming to Steel grade per IS 1762:1974 latest ammendment |
HCHCr |
| Electrical power rating of the motor is 415 VAC,3Ph,50Hz |
YES |
| Over load Protection system available |
Yes |
| Erection and Commissioning by Seller, at site before acceptance by Buyer: |
YES |
| Material of the shaft |
Carbon Steel |
| Trolley or Bins provided to Collect waste |
Yes |
| Switch to reverse cutter rotation available |
Yes |
| Capacity of the waste collection Trolley or bin (L) |
35 |
| Shredding capacity |
25 kg/hour |
| Gross weight of the machine (Metric Ton) |
310 kilogram |
| Tensile strength of the shaft (MPa) |
520 |
| Maximum RPM of the cutter (RPM) |
100 |
| Type of waste that can be treated as per Bio-Medical Waste Management Rules, 2016 |
Contaminated Waste Recyclable |
| Gear Box for speed reduction |
Yes |
| Input Electrical Supply requirement (A,VAC,Ph,Hz) |
10A,440V,3,50Hz |
| Finish of enclosure |
Powder coated |
| Additional Safety Features |
Door Cut Off |
Warranty
| Warranty (with free spare parts and free service) on Machine |
5 year |
| Number of Preventative maintenance visits during warranty (number per annum) |
3 |
SHREDDING CHAMBER
| Size of Shredding chamber (Length X width x xHeight) (mm x mm x mm) |
260x200x200 |
| Shredding chamber Height |
200 millimeter |
WASTE LOADING CHAMBER
| waste Loading method to chamber |
Hopper |
| Size of loading chamber opening (mmxmm) |
260x280 |
| Size of loading chamber opening:Width |
300 millimeter |
| Size of Shredding chamber: Length |
280 millimeter |
| Size of Shredding chamber: Width |
220 millimeter |
| Size of loading chamber opening:Length |
260 millimeter |
CERTIFICATIONS
| Electrical Safety requirement as per IS 302-1:2008 latest amendment |
YES |
| Availability of Test Report from Central Govt./NABL/ILAC accredited lab to prove conformity to specification |
Yes |
| Test Report Number and Date |
2074/C0842 |
| Name and address of the Lab |
NIIRT, Panchkula, Haryana |
| Other Certifications |
CE, ISO-13485:2016, NSIC |
| Firm Certified to ISO9001:2008 or latest |
Yes |
| Product code available on supplier website |
Yes |
| Product code |
ESTWS-101 |
OVERALL DIMENSIONS
| External Dimension: Height |
1750 millimeter |
| External Dimension: Width |
1250 millimeter |
| External Dimension: Depth |
1050 millimeter |
